This Slub Spinning System is a high mech-electrical technology product, which is driven and controlled automatically by number-servo control system, automatically controlling the whole spinning processes (including Slub length, pitches and thickness). It is very easy for customers to develop new products and change spinning processes, almost no limit at all.
It is very easy for customers to edit the program for the spinning processes. You can directly edit the program on the Touch-screen on site and you can also edit the program on your computer at your office, and then copy it to the system by a movable disk.
Spinnable Range: Ne 1-80 pure cotton, ramie and cotton blends and chemical fibers and their blends;
Spinning Mode: Regular cycling; Random cycling; Slub-plus-Slub; Ratio illegible; Different illegible and Random value and etc.
Slub length:20mmand more; Slub pitch: 30mm and more; Thickness: 50-600%.
1、High Technology and high accuracy:A special advanced technology which can close dynamically follows up with the frame can be response to the system at a speed of 1ms, ensuring quality Slub Yarns when the frame starts or stops, even as the frame’s speed is waving up and down, especially suitable for the frame that is controlled by inverter.
2、A wonderful man-machine dialogue interface:A color touch-screen display, easy for operation.
3、An optional Program Managing System:It can manage 10000 varieties of Slub Yarns.and then copy it to the system by a movable disk.
ZNZ Intelligent Slubby Yarn Control is the upgrade production Of the normal Slubby Yarn Control which is controlled by servomotor. It contains quality manage、alarm system、technical storage manage system、technical parameter designed by computer expert,and the spinning can be selected in random.The realization of these functions is convenient for the production factory,which reduces the bother,improves the work efficiency and creates more economy benenfot
